BAADER 600-501 Soft Separator
Separating Meat from Bones, Skin, and Tendons
The BAADER 600-501 Soft Separator is a soft separator from the BAADER brand, designed to separate meat and other soft components from bones, skin, cartilage, and tendons. The unit uses the patented BAADERING method, in which a flexible squeezing belt presses raw material through a perforated drum — soft parts pass through the sieve openings, while hard elements remain on the outside of the drum.
How does the BAADER 600-501 Soft Separator work?
Raw material is fed onto a flexible squeezing belt, which transports it to the perforated sieve drum. Under adjustable pressure, the soft parts of the raw material — meat, minced meat, pulp — are pressed through the sieve openings, 3 mm in diameter, while bones, skin, cartilage, and tendons remain on the outside of the drum and are automatically discharged. The final texture of the resulting product depends on the type of raw material processed and the sieve hole diameter used.
The separator’s gentle mode of operation preserves the structure of muscle fibers and produces a product with low calcium content and high binding capacity, while maintaining the desired appearance and color.
Key advantages of the BAADER 600-501 Soft Separator
The BAADERING method effectively separates soft components from hard ones while maintaining a high quality of the resulting product — without excessive breakdown of muscle fibers or overheating of the raw material. Adjustable pressure allows the intensity of the process to be matched to the type of raw material processed, and the availability of sieves with different hole diameters (standard 1.3, 2, 3, 4, or 5 mm) allows the product structure to be tailored to its further application.
The compact design, low weight (290 kg), and electropolished working surfaces make daily operation, cleaning, and maintaining the high hygiene standard required in the food industry straightforward.
Technical specifications of the BAADER 600-501 Soft Separator
- Manufacturer: BAADER Food Processing Machinery, Nordischer Maschinenbau Rud. Baader GmbH+Co.KG, D-23560 Lübeck
- Type: 600-501
- Designation: Soft Separator
- Year of manufacture: 2011
- Project/serial number: 120000877/10
- Power supply: 400 V, 3-phase, 50 Hz
- Power: 3.0 hp / 2.2 kW
- Rated current: 5.6 A
- Wiring diagram number: 600.70.00.855
- Weight: 290 kg
- Machine dimensions (L x W x H): 1060 x 800 x 1150 mm
- Sieve: 3 mm hole diameter
- Compliance: CE, Made in Germany
Application of the BAADER 600-501 Soft Separator
The BAADER 600-501 Soft Separator is used in meat, poultry, and fish processing plants — for desinewing red meat, standardizing poultry meat, separating fish meat from bones, skin, and cartilage, and also in shellfish processing. The separator performs well wherever gentle yet effective separation of soft raw material components from hard ones is required, while maintaining a high quality finished product.
BAADER 600-501 Soft Separator available at BMG Trade
At BMG Trade, we specialize in trading machinery for the food industry, including proven separators from renowned brands such as BAADER. The 600-501 Soft Separator we offer, manufactured in 2011, is fitted with a 3 mm sieve and ready for operation in a production facility. Contact us to find out about current availability and pricing for the BAADER 600-501 Soft Separator.
