RISCO RS 503
Vacuum filler with capacity up to 6,500 kg/h
The RISCO RS 503 vacuum filler is a high-capacity machine from the RISCO brand, manufactured in 2005, designed for filling and portioning meat mixtures in large food processing plants. With a capacity of up to 6,500 kg/h, a portioning speed of up to 700 portions per minute, and a 350-liter hopper suited to 200 l trolleys, the unit performs well in high-volume production.
How does the RISCO RS 503 vacuum filler work?
Raw material goes into the 350-liter hopper, which can be fed directly from 200 l trolleys. Operating under vacuum removes air from the mass, while a vane pump with a feeding system ensures a continuous, stable flow of product to the machine outlet. The servo drive and a multifunction controller allow precise setting of filling parameters and portion size, and quick connection to other equipment such as clippers, forming machines, or packaging lines makes it possible to build complete production lines. In a configuration with an integrated RS 70 linear grinder, the machine can fill and grind the raw material at the same time.
Key advantages of the RISCO RS 503 vacuum filler
High capacity of up to 6,500 kg/h and a portioning speed of up to 700 portions/min allow continuous work with large batches of raw material, which is crucial in high-volume plants. The large 350 l hopper matched to 200 l trolleys reduces the number of refills and shortens downtime.
Vacuum operation improves the uniformity and structure of the mass and limits air pockets in finished products. The servo drive and simple parameter control make it easy to adapt the machine to different recipes, and the solid construction with a weight of approx. 1,060 kg ensures stable operation under intensive use.
Technical specifications of the RISCO RS 503 vacuum filler
- Manufacturer: RISCO
- Stuffer model: RS 503
- Year of manufacture: 2005
- Filling machine power supply: 400 V, 3 phases, 50 Hz
- Installed power: 14 kW
- Filling machine weight: approx. 1,060 kg
- Filling capacity: up to 6,500 kg/h
- Portioning speed: up to 700 portions/min
- Hopper capacity: 350 l (for 200 l trolleys)
Application of the RISCO RS 503 vacuum filler
The RISCO RS 503 vacuum filler is used in large meat and food processing plants for producing sausages, cold cuts, minced meat, fillings, and formed products. Thanks to its ability to work with clippers, forming machines, and other equipment, it suits automated production lines.
RISCO RS 503 vacuum filler available at BMG Trade
At BMG Trade, we specialize in trading machinery for the food industry, including proven vacuum fillers from the renowned RISCO brand. The RS 503 filler we offer, from 2005, is a high-capacity 14 kW unit, ready for operation in a production facility. Contact us to find out about current availability and pricing for the RISCO RS 503 vacuum filler.
Frequently asked questions about the RISCO RS 503 vacuum filler
What is the portioning speed of the RISCO RS 503 filler? The filler allows portioning at up to 700 portions per minute, with a filling capacity of up to 6,500 kg/h.
What is the hopper capacity of the RISCO RS 503 filler? The hopper has a capacity of 350 liters and is suited to 200 l trolleys.
